Make Counter use seven segment display and PIC Microcontroller

In this tutorial we will learn how to make counter use 7 segment display use PIC Microcontroller. Here I am use PIC16F877A micrcorontroller and 3 digit seven segment display.

You can watch the following video or read the written tutorial below.

7 segment display

seven segment display has 7 segment and each segment emit light. When segment a,b,c,d,e & f emit light than the display show the decimal value 0.

3 digit 7 segment display

0.56'' - digit size

Circuit Diagram

Mikro C Code:

	// Common Cathod display
	# define SW1 PORTC.RC0
	# define SW2 PORTC.RC1
	char display[10] = {0x3F,0x06,0x5B,0x4F,0x66,0x6D,0x7D,0x07,0x7F,0x6F};
	int i = 0;
	char digit1,digit2,digit3;
	void main() {
	TRISB = 0X00;
	TRISD = 0X00;
	PORTB = 0X00;
	PORTD = 0X00;
	while(1){

	if(SW1==1){
	//while(SW1==1);
	i++;
	delay_ms(250);
	}
	if(SW2==1){
	//while(SW2==1);
	i--;
	delay_ms(250);
	}
	if(i==1000) i ==0;
	if(i==-1) i =0;
	digit1 = i/100;
	digit2 = (i/10)%10;
	digit3 = i%10;

	PORTB = display[digit1];
	PORTD = 0X01;
	delay_ms(5);
	PORTD = 0X00;

	PORTB = display[digit2];
	PORTD = 0X02;
	delay_ms(5);
	PORTD = 0X00;

	PORTB = display[digit3];
	PORTD = 0X04;
	delay_ms(5);
	PORTD = 0X00;

	}


	}
