Lcd display with PIC microcontroller and Mikro C compiler

In this tutorial you will learn how to interface LCD whit PIC16F877A Microcontroller. You can watch the video or read the written tutorial below.

LM16x2 Lcd Display

LCD means Liquid Crystal Display. In this project I am use LM 16X2 LCD Display. 16X2 means 16 column & 2 row in this display. There are 16*2 = 32 segment in this display. Each segment hold
8x2 dot patterns. There are 16 pin for connections.

LM16x2 Lcd display

16 column & 2 row

dot segment

pin configuration

circuit schematic

Component needed for this project

1. PIC16F877A
2. 8MHz Crystal
3. LM16x2 Lcd display
4. 10K POT
5. 10K
6. Breadboad
7. Connection wire
8. PICkit 2
9. PC
10. PIC Universal Programmer Adaptor

In this tutorial I am use Mikro C Pro For PIC compiler for coding. Mikro C Pro For Pic provide  a comfortable LCD library for LCD interfacing.

MIKRO C PRO FOR PIC LCD Library

The mikroC PRO for PIC provides a library for communication with Lcds (with HD44780 compliant controllers) through the 4-bit interface.

Lcd Library Routines

• Lcd_Init
• Lcd_Out
• Lcd_Out_Cp
• Lcd_Chr
• Lcd_Chr_Cp
• Lcd_Cmd

Mikro C code :

	// Lcd module connections
	sbit LCD_RS at RB0_bit;
	sbit LCD_EN at RB1_bit;
	sbit LCD_D4 at RB2_bit;
	sbit LCD_D5 at RB3_bit;
	sbit LCD_D6 at RB4_bit;
	sbit LCD_D7 at RB5_bit;
	sbit LCD_RS_Direction at TRISB0_bit;
	sbit LCD_EN_Direction at TRISB1_bit;
	sbit LCD_D4_Direction at TRISB2_bit;
	sbit LCD_D5_Direction at TRISB3_bit;
	sbit LCD_D6_Direction at TRISB4_bit;
	sbit LCD_D7_Direction at TRISB5_bit;
	// End Lcd module connections
	void main() {
	Lcd_Init(); // Initialize Lcd module
	Lcd_Cmd(_LCD_CLEAR); // Clear Lcd display
	Lcd_Cmd(_LCD_CURSOR_OFF); // Lcd cursor off
	while(1){ // Endless loop
	Lcd_Out(1,3,"WELCOME TO"); // 1st row,3rd column to start writting
	delay_ms(1000); // 1second delay
	Lcd_Out(2,1,"MINA TECHNOLOGY"); // 2nd row, 1st column to start writting
	delay_ms(1000); // 1second delay
	Lcd_Cmd(_LCD_CLEAR); // Clear Lcd display
	Lcd_Out(1,3,"DEVELOPED BY"); // 1st row,1st column to start writting
	delay_ms(1000); // 1second delay
	Lcd_Out(2,1,"MINA TECHNOLOGY"); // 2nd row, 1st column to start writting
	delay_ms(1000); // 1second delay
	Lcd_Cmd(_LCD_CLEAR); // Clear Lcd display
	}
	}

view raw LCD module interfacing hosted with ❤ by GitHub

Code describe:

First time here I write codes for Lcd module connections and intialize Lcd in main funciton. Than I clear the Lcd and off the cursor.

Download here for hex file. Click download button.

download
